Enova® Aerogel IC3110 Fine Particles from Cabot Aerogel
Enova® Aerogel IC3110 Fine Particles from Cabot AerogelEnova® Aerogel IC3110 Fine Particles from Cabot AerogelEnova® Aerogel IC3110 Fine ParticlesEnova® Aerogel IC3110 Fine Particles from Cabot Aerogel

Enova® Aerogel IC3110 Particles

From: $82

Enova® Aerogel IC3110 fine particles from Cabot Aerogel is a fine-particle performance additive suited for insulative coatings.  With a thermal conductivity half that of still air and a particle size that can deliver a smooth, even coat, Enova aerogel is ideal for a variety of thin-film insulative coatings applications.

Particle size range is 100-700 µm (0.1-0.7 mm). Particle density is 120-150 kg/m3. Thermal conductivity is 0.012 W/m-K at 25°C.

Not sure which aerogel particle is right for your application?  View our Aerogel Particle Selection Guide.

Additional information available in the Enova Aerogel IC3110. Download the United States MSDS or the European MSDS.

For volume price indication for market assessments or business case studies please contact Cabot Aerogel directly here.

Clear selection

Product Description

Enova® Aerogel IC3110 from Cabot Aerogel is a fine-particle performance additive suited for insulative coatings.  With a thermal conductivity half that of still air and a particle size that can deliver a smooth, even coat, Enova aerogel is ideal for a variety of thin-film insulative coatings applications.

Enova aerogel enables coatings that provide functional advantages including:

  • Ultralow thermal conductivity
  • Extreme resistance to shear
  • Safe-touch performance for personal protection
  • Complete hydrophobicity
  • Smooth, even finish

Particle size range is 100-700 µm (0.1-0.7 mm). Particle density is 120-150 kg/m3. Thermal conductivity is 0.012 W/m-K at 25°C.

Particle Type
 IC3100  IC3110  IC3120
Particle Size
 2-40 µm
100-700 µm (0.1-0.7 mm)  100-1200 µm (0.1-1.2 mm)
Pore Diameter ~20 nm ~20 nm ~20 nm
Particle Density 120-150 kg/m3 (7.5-9.4 lb/ft3, 1-1.25 lb/gal [US]) 120-150 kg/m3 (7.5-9.4 lb/ft3, 1-1.25 lb/gal [US]) 120-150 kg/m3 (7.5-9.4 lb/ft3, 1-1.25 lb/gal [US])
Surface Chemistry Hydrophobic Hydrophobic Hydrophobic
Surface Area
600-800 m2/g 600-800 m2/g 600-800 m2/g
Thermal Conductivity 0.012 W/m-K
(0.083 BTU-in/h-ft2-°F) at 25°C (77°F)
0.012 W/m-K
(0.083 BTU-in/h-ft2-°F) at 25°C (77°F)
0.012 W/m-K
(0.083 BTU-in/h-ft2-°F) at 25°C (77°F)
CAS RN
102262-30-6 102262-30-6 102262-30-6

Additional information available in the Enova Aerogel IC3110. Download the United States MSDS or the European MSDS.

For volume price indication for market assessments or business case studies please contact Cabot Aerogel directly here.

Additional Information

Weight 8 oz
Dimensions 6 x 6 x 8 in
Size

1 L, 20 L
